electrode stand, USB cable, and universal AC power adapter.
Key Features
Large easy-to-read graphical display with backlight
Plug-and-play sensors for pH, ORD, conductivity, resistivity, TDS, salinity, and optical DO/BOD
Digital sensor recognition, processing, and data transfer
Quality Sensor Control (QSC) system monitors the condition of pH electrodes
Continuous monitoring (CMC) function verifies sensor's measuring range against calibration range
Data logging with GLP time-and-date traceability and USB connectivity
More About this Item
YSI MultiLab line of one-, two-, and three-channel meters provide maximum flexibility with smart sensor recognition. The Intelligent Design Sensors (IDS) plug-and-play feature lets you decide the meter''s operation. Plug in a pH electrode and its a pH meter; replace with a conductivity probe and its a conductivity meter; same for oxygen--it is that easy!
The IP64-rated waterproof meters feature a large graphical display with backlight, manual and automatic data logging with GLP traceability, and convenient USB data transfer. Quality QSC and CMC functions ensure proper functioning of the electrode within the calibration range of meter.
The IDS electrodes digitally store their serial number, electrode type, unique ID, and calibration data. The sensors can also be moved from one meter to another and transfer their calibration data.
pH Kit contains a single-channel meter and a IDS pH double junction IDS sensor. Meter can be made a conductivity or DO meter simply with the purchase of a sensor.(Note: Single-channel meters do not work with the BNC adapter.)
Specifications
Meter TypeBenchtop
Display typeLCD
Min pH (pH)0
Max pH (pH)14
pH Resolution0.001
pH Accuracy±0.004
Buffer RecognitionAutomatic
mV Resolution1 mV
mV Accuracy±1
Min Conductivity10 µS to 2000 mS
Max Conductivity2000 mS
Conductivity Resolution0.1 µS
Conductivity Accuracy±0.5% of reading
Min TDS0 to 1999 ppm
TDS Resolution0.1 ppt
Min Salinity0.0 to 70.0 ppt
Salinity Resolution0.1 ppt
Salinity Accuracy±0.5% of reading
Min Resistivity0.5 to 100 kΩ
Resistivity Resolution0.1 mΩ; 0.1 kΩ; 0.1 MΩ
Resistivity Accuracy±0.5% of reading
Min Dissolved Oxygen0 to 50 ppm; 0 to 500%
InterfaceUSB
WaterproofYes
Power (VAC)100 to 240
Power (Hz)50 or 60
Width (cm)19.05
Height (cm)7.9375
Width (in)7 1/2
Height (in)3 1/8
Probe IncludedYes
DescriptionMultiLab Single-Channel pH Benchtop Meter Kit
